The Aruba CX 6300 48G PoE+ 4SFP+ Switch (JL660A) is a powerful stackable Layer 3 switch designed for enterprise access, aggregation, and core deployments. Built on Aruba’s modern AOS-CX operating system, this switch supports advanced cloud-native features for automation, security, and scale. It includes 48 multi-gigabit ports (1/2.5/5GbE) with PoE capabilities and 4 high-speed uplink ports supporting up to 50GbE, making it a future-ready access switch for bandwidth-intensive environments.
With a system switching capacity of 880 Gbps and up to 660 Mpps throughput, JL660A supports high-density deployments and services such as BGP, EVPN, VXLAN, and OSPF. It also enables policy-driven access with Aruba Dynamic Segmentation and zero-touch deployment via the Aruba CX Mobile App. Aruba NetEdit provides automation and configuration validation, while Aruba Network Analytics Engine ensures deep visibility and faster remediation.
Transceiver Compatibility: Aruba J4858D
The Aruba JL660A switch supports the Aruba 1G SFP LC SX Transceiver (J4858D), enabling high-speed fiber connectivity over multimode fiber (MMF). Below are the key specifications:
- SKU: J4858D – Aruba 1G SFP LC SX 500m MMF XCVR
- Digital Optical Monitoring: Yes (1990-4395 & 1990-4415)
- Central Wavelength: 850 nm
- Fiber Mode: MMF
- Fiber Diameter: 50/125 µm or 62.5/125 µm
- Modal Bandwidth: OM2: 500 MHz*km / OM1: 200 MHz*km
- Transmission Distance: Up to 550 m (OM2) or 275 m (OM1)
Perfect for future-proofing enterprise networks, the JL660A offers performance, scale, and flexibility with advanced visibility and operational efficiency—making it a top-tier solution for access to core switching.
