The Aruba CX 6100 24G PoE+ 4SFP+ Switch (JL677A) is a compact, energy-efficient Layer 2 managed switch designed for enterprise branch offices and SMBs. As part of the Aruba CX 6100 Series, it delivers secure, reliable, and high-performance access with 24 Gigabit Ethernet ports and built-in uplinks. With a low power consumption of just 32.70W and fanless design, JL677A is ideal for noise-sensitive environments.
This model offers full support for ACLs, static routing, robust QoS, and modern APIs for software-defined networking. Colorless ports simplify adds, moves, and changes, while Aruba NetEdit and Aruba Central enable centralized, automated configuration and monitoring. With 370W PoE power support, it powers devices like access points, phones, and IP cameras—all through a single cable.
Transceiver Compatibility: Aruba J4858D
The Aruba JL677A switch supports the Aruba 1G SFP LC SX Transceiver (J4858D), enabling high-speed fiber connectivity over multimode fiber (MMF). Below are the key specifications:
- SKU: J4858D – Aruba 1G SFP LC SX 500m MMF XCVR
- Digital Optical Monitoring: Yes (1990-4395 & 1990-4415)
- Central Wavelength: 850 nm
- Fiber Mode: MMF
- Fiber Diameter: 50/125 µm or 62.5/125 µm
- Modal Bandwidth: OM2: 500 MHz*km / OM1: 200 MHz*km
- Transmission Distance: Up to 550 m (OM2) or 275 m (OM1)
Offering reliable PoE performance, quiet operation, and simplified centralized management, the JL677A is perfect for access-layer deployments that require modern capabilities with a low operational footprint.
