Product Specifications

HPE ProLiant DL380 Gen10 6248R Rack Server

Key features and specifications

Processor: It is powered by Intel Xeon Scalable processors, and specifically, the 6248R is an Intel Xeon Gold 6248R processor. It is a 2nd generation Intel Xeon Scalable processor with 24 cores, 48 threads, and a base clock speed of 3.0 GHz.

Memory: The DL380 Gen10 supports up to 3TB of DDR4 memory using 24 DIMM slots. It supports various memory configurations, including RDIMM, LRDIMM, and NVDIMM.

Storage: It offers a wide range of storage options, including hot-plug SFF (Small Form Factor) and LFF (Large Form Factor) SAS/SATA HDDs and SSDs. The server supports up to 30 SFF or 20 LFF drives, providing high storage capacity and flexibility.

Expansion Slots: The DL380 Gen10 comes with a variety of PCIe expansion slots, including three PCIe 3.0 x16 slots, three PCIe 3.0 x8 slots, and one dedicated PCIe 3.0 x16 slot for an HPE FlexibleLOM Network Adapter.

Networking: It supports HPE FlexibleLOM adapters for network connectivity, allowing you to customize and choose the network interface that suits your needs.

Management and Security: The server includes HPE Integrated Lights-Out (iLO) for remote management, monitoring, and control of the server. iLO enables out-of-band management and provides advanced security features like Secure Boot, Silicon Root of Trust, and more.

Power Supply: The DL380 Gen10 comes with redundant power supply options, providing high availability and power efficiency. It supports multiple power supply units, including 800W, 1600W, and 1700W options.

Form Factor: It is a 2U rack server, designed to be installed in standard data center racks. The rack-mountable form factor allows for efficient space utilization and easy deployment in data center environments.
